 | Kategorier |  | |  | Produsenter | | | | | | Informasjon | | | | | | Eurolite DMX Power Splitter 4x4 3-pin XLR 10A99G94
Leveringstid: 6 til 10 dager. | |
| |
| | 1 in/4 out power and DMX splitter with RDM support for rack mounting - 1 P-Con input to 4 outputs, max. 16 A
- 1 DMX input to 4 outputs
- 1 DMX feed-through output
- Switchable RDM filter mode
- Switchable termination resistor
- Input and outputs galvanically isolated
- Each DMX output with independent driver and status indicator
- Control via RDM
- (19) 48.3 cm rack installation 1 U
- 1 x device, 1 x user manual, 1 x power cord
| Power supply: | 100-240 V AC, 50/60 Hz | | Power consumption: | 5 W | | Protection class: | Protection class I | | Output current: | Max. 4 x 4 A per channal | | Power connection: | Via P-Con (blue), mounting version | | Power output: | 4 x P-Con (gray), mounting version | | Fuse: | 5 x 20 mm, T 1 A Fuse replaceable | | DMX input: | 1 x 3-pin XLR (M) | | DMX output: | 4 x 3-pin XLR (F) with independent driver and status indicator | | Control: | RDM | | Housing design: | (19") 48.3 cm rack installation 1 U | | Dimensions: | Width: 48,3 cm
Depth: 13,8 cm
Height: 4,3 cm | | Weight: | 2,56 kg |

 | | | | |
